12 scanners of 16 channels each
30 banks have 8 programmable scenes each
6 programmable chase have 240 scenes each
8 slider for manual control of channels
2 assignable wheels for ease of movement
File dump allows data to be sent for received between 2 units auto mode program controlled by speed and fade time sliders
l All fade time adjustable
Reversible DMX channels fixture to react in opposition to others in a chase
8 channel or 16 channel mode
Fine adjustment for Wheel pan and tilt
Blackout master button
Manual override button allow you to grab any fixture on the fly
Built in microphone for music triggering
Midi control over banks, chases and blackout
DMX polarity selector
Power failure memory
Fog machine connector
LED lamp connector
Power input: DC 9-12V 1000mA
Audio input: by built-in microphone or line in, 100mv-1vpp
DMX in/out: 3 pin male/female XRL
Midi in: 5 pin multiple socket
Dimensions(mm): 482 ¡Á 190 ¡Á90
Net Weight: 2.6kg
